j5create JUE130 USB™ 3.0 Gigabit Ethernet Adapter, Silver and White
- Instant connection to a wired network over USB™
- USB™ 3.0 provides up to 5 Gbps transfer rate, which is 10x faster than USB™ 2.0
- Backwards compatible with USB™ 3.0, 2.0, and 1.1 hosts and devices
- LED activity indicator
The USB™ 3.0 Gigabit Ethernet Adapter gives you the ability to add a Gigabit Ethernet port to your laptop or MacBook® though a single USB™ 3.0 Type-A port, supporting 10/100/1000 Mbps Ethernet and is fully compatible with IEEE 802.3/az/u/ab/x standards.
This ethernet adapter provides full gigabit bandwidth and offers backward compatibility with USB™ 2.0. It also supports features such as IPv4/IPv6/TCP/UDP packet Checksum Offload Engine (COE) and TCP Large Send Offload to reduce the load on your CPU. Jumbo Frames, full-duplex operation, VLAN tagging and 2 VLAN ID filtering are also supported, making this an ideal replacement LAN adapter or laptop accessory in areas without Wi-Fi® or if you just want to increase your Internet speed.
| Ports & interfaces |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB connector form factor |
Straight |
| Ethernet LAN (RJ-45) ports |
1 |
| Interface |
Ethernet |
| Host interface |
USB |
| Connectivity technology |
Wired |
| Network |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Maximum data transfer rate |
1000 Mbit/s |
| Design |
| Country of origin |
Taiwan |
| LED indicators |
Activity, Link |
| Product colour |
Silver, White |
| Component for |
PC/Laptop |
| Internal |
No |
| Power |
| Power consumption (typical) |
1 W |
| Output current |
0.2 A |
| Output voltage |
5 V |
| System requirements |
| Other operating systems supported |
ChromeOS |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Compatible operating systems |
Windows, Mac, Linux |
| Operational conditions |
| Storage temperature (T-T) |
-42 – 82 °C |
| Operating temperature (T-T) |
0 – 40 °C |
| Weight & dimensions |
| Weight |
35 g |
| Height |
23 mm |
| Depth |
14.5 mm |
| Width |
68 mm |
| Packaging data |
| Package weight |
76.5 g |
| Package height |
25 mm |
| Package depth |
97 mm |
| Package width |
120 mm |
| Packaging content |
| Packaging content |
1 x JUE130 USB™ 3.0 Gigabit Ethernet Adapter, 1 x Quick Installation Guide, 1 x Driver Installation CD |
| Batteries included |
No |
| Technical details |
| Warranty period |
2 year(s) |
| Logistics data |
| Minimum order quantity |
60 pc(s) |
| Products per master (outer) case |
20 pc(s) |
| Master (outer) case gross weight |
2.17 kg |
| Master (outer) case height |
145 mm |
| Master (outer) case length |
210 mm |
| Master (outer) case width |
280 mm |
| Master (outer) case GTIN (EAN/UPC) |
24712795080241 |
| Other features |
| Recommended operating temperature range (T-T) |
0 – 40 °C |
| Contents |
1 x JUE130 USB™ 3.0 Gigabit Ethernet Adapter, 1 x Quick Installation Guide |
| Quantity per pack |
1 pc(s) |
| Compatibility |
Backwards compatible with USB™ 3.0, 2.0, and 1.1 hosts and devices, Instant connection to a wired network over USB™Devices include:Macbook™ Pro (Up to model year 2015)Macbook™ Air (Up to model year 2017)Surface Pro™ 7Surfacebook™ |
| Export Control Classification Number (ECCN) |
EAR99 |
| Commodity Classification Automated Tracking System (CCATS) |
8471.80.0000 |
| Cable length |
0.145 m |
| Quick start guide |
Yes |
| Cable type |
USB 3.0 |
| Housing material |
Aluminium |
