TieDex UK Wasp WDI7500 – barcode scanner
Wasp WDI7500 – Barcode scanner – handheld – 2D imager – decoded – USB
Basic Specifications
- Manufacturer’s Part Number
- 633809002830
- EAN
- 0633809002830
- Product Type
- Barcode Scanner
- Dimensions (WxDxH)
- 11 cm x 7.4 cm x 21.2 cm
- Colour
- Black, yellow
- Manufacturer Warranty
- 2-year warranty
- Type
- Barcode scanner – handheld – USB – decoded
- Weight
- 330 g
- Product Description
- Wasp WDI7500 – barcode scanner
- Model
- Wasp WDI7500
- Connectivity Technology
- Wired
- Sensor Resolution
- 864 x 544
- Minimum Bar Width
- 4 mil
- Scan Element Type
- 2D imager
Expansion / Connectivity
- Interfaces
- 1 x USB – Type A
Power
- Electric Current Required
- 335 mA (operating), 180 mA (standby)
Environmental Parameters
- Min Operating Temperature
- -20 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 0 – 95% (non-condensing)
- Drop Specification
- 2 m
General
- Type
- Barcode scanner – handheld
- Colour
- Black, yellow
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Dimensions & Weight
- Width
- 11 cm
- Depth
- 7.4 cm
- Height
- 21.2 cm
- Weight
- 330 g
Miscellaneous
- Cables Included
- 1 x USB cable – 1.8 m
- Compliant Standards
- FCC Part 15 B, RoHS, WEEE, REACH, IP65, IEC 62471
Barcode
- Interface Type
- USB
- Minimum Bar Width
- 4 mil
- Scan Element Type
- 2D imager
- Sensor Resolution
- 864 x 544
- Light Source Wave Length
- 630-680 nm
- Skew (Degrees)
- 40
- Pitch (Degrees)
- 40
- Print Contrast Signal (PCS)
- 15%
- Decode Capability
- EAN/JAN, QR code, MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, China Post, Japanese Post, Kix (Netherlands) Post, MacroPDF417, Royal Mail, Micro QR code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, Swedish Post, GS1 DataBar Composites, GS1 DataBar Stacked, China Han Xin Code, Portuguese Post, UPC-A / E
- TTL Decoding
- Decoded
- Connectivity Technology
- Wired
- OK Notification
- Beeper, LED indicator
- Features
- Triggered, ESD (electrostatic discharge) safe, rugged
