Kingston Technology ValueRAM KVR32S22S6/4 memory module 4 GB 1 x 4 GB DDR4 3200 MHz
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Single-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
ValueRAM, Kingston’s industry standard memory, delivers award-winning performance and legendary Kingston reliability. When you know what you want, you want ValueRAM.
| Features |
| JEDEC standard |
Yes |
| Lead plating |
Gold |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
45.75 ns |
| Module configuration |
512M x 64 |
| Memory voltage |
1.2 V |
| CAS latency |
22 |
| ECC |
No |
| Memory form factor |
260-pin SO-DIMM |
| Component for |
Laptop |
| Memory clock speed |
3200 MHz |
| Internal memory type |
DDR4 |
| Memory layout (modules x size) |
1 x 4 GB |
| Internal memory |
4 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Operational conditions |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
0 – 85 °C |
| General |
| Product family |
ValueRAM |
| Technical details |
| Compliance certificates |
RoHS |
| Sustainability |
| Doesn’t contain |
Halogen |
| Weight & dimensions |
| Height |
30 mm |
| Depth |
2.45 mm |
| Width |
69.6 mm |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
