Intel Xeon w9-3575X processor 2.2 GHz 97.5 MB Smart Cache
- Intel Xeon W w9-3575X 2.2 GHz
- 97.5 MB Smart Cache FCLGA4677
- Processor cores: 44 64-bit
- Maximum internal memory supported by processor: 4 TB DDR5-SDRAM
| Processor | |
|---|---|
| Processor ARK ID | 240501 |
| Processor codename | Sapphire Rapids |
| Processor base power | 340 W |
| Maximum turbo power | 408 W |
| Processor cache type | Smart Cache |
| Processor cache | 97.5 MB |
| Processor boost frequency | 4.8 GHz |
| Performance cores | 44 |
| Processor operating modes | 64-bit |
| Intel® UPI Speed | 0 GT/s |
| Processor threads | 88 |
| Box | No |
| Processor socket | FCLGA4677 |
| Processor cores | 44 |
| Processor base frequency | 2.2 GHz |
| Processor model | w9-3575X |
| Processor family | Intel Xeon W |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory clock speeds supported by processor | 4800 MHz |
| Memory types supported by processor | DDR5-SDRAM |
| Maximum internal memory supported by processor | 4 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 1S |
| Embedded options available | No |
| Direct Media Interface (DMI) Revision | 4.0 |
| CPU configuration (max) | 1 |
| Supported instruction sets | AMX, AVX 2.0, AVX-512, SSE4.1, SSE4.2 |
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 112 |
| Use conditions | Workstation |
| Market segment | Workstation |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® In-memory Analytics Accelerator (IAA) | 0 default devices |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® Dynamic Load Balancer (DLB) | 0 default devices |
| Intel® QuickAssist Technology (QAT) | 0 default devices |
| Intel® Threat Detection Technology (TDT) | No |
| Intel vPro® Enterprise Platform Eligibility | Yes |
| Intel® Total Memory Encryption – Multi Key | No |
| Intel® QuickAssist Software Acceleration | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel® Active Management Technology (Intel® AMT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® One-Click Recovery | No |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | No |
| Intel® Remote Platform Erase (RPE) | No |
| Intel® OS Guard | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel® Boot Guard | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.8 GHz |
| Intel® Turbo Boost Technology 2.0 frequency | 4.6 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Operational conditions | |
|---|---|
| Tcase | 79 °C |
| DTS Max | 100 °C |
| Technical details | |
|---|---|
| Launch date | Q3’24 |
| Status | Launched |
| Memory speed (max) | 4800 MHz |
| Package carrier | E1A |
| Weight & dimensions | |
|---|---|
| Processor package size | 77.5 x 56.5 mm |
| Other features | |
|---|---|
| Maximum internal memory | 4 TB |
