Intel Xeon E7-4830 processor 2.13 GHz 24 MB Smart Cache Box
- Intel® Xeon® E7 Family E7-4830 2.13 GHz
- 24 MB Smart Cache LGA 1567 (Socket LS)
- Processor cores: 8 32 nm 64-bit 105 W
- Maximum internal memory supported by processor: 2.05 TB DDR3-SDRAM
- Box Cooler included
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor’s frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
| Processor |
| Processor ARK ID |
53676 |
| Processor code |
SLC3Q |
| Processor codename |
Westmere EX |
| CPU multiplier (bus/core ratio) |
16 |
| Bus type |
QPI |
| Stepping |
A2 |
| Processor front side bus |
1333 MHz |
| Thermal Design Power (TDP) |
105 W |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor boost frequency |
2.4 GHz |
| Processor operating modes |
64-bit |
| System bus rate |
6.4 GT/s |
| Processor threads |
16 |
| Processor series |
Intel Xeon E7-4800 |
| Component for |
Server/workstation |
| Cooler included |
Yes |
| Box |
Yes |
| Processor lithography |
32 nm |
| Processor socket |
LGA 1567 (Socket LS) |
| Processor cores |
8 |
| Processor base frequency |
2.13 GHz |
| Processor model |
E7-4830 |
| Processor family |
Intel® Xeon® E7 Family |
| Processor manufacturer |
Intel |
| Memory |
| ECC |
Yes |
| Memory channels |
Quad-channel |
| Memory types supported by processor |
DDR3-SDRAM |
| Maximum internal memory supported by processor |
2.05 TB |
| Features |
| Commodity Classification Automated Tracking System (CCATS) |
G077159 |
| Export Control Classification Number (ECCN) |
5A992C |
| Scalability |
S4S |
| Embedded options available |
No |
| CPU configuration (max) |
4 |
| Supported instruction sets |
SSE4.1, SSE4.2 |
| Market segment |
Server |
| Execute Disable Bit |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Processor special features |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Conflict-Free processor |
No |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
1.0 |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| General |
| Product family |
Xeon |
| Operational conditions |
| Tcase |
64 °C |
| Logistics data |
| Harmonized System (HS) code |
85423119 |
| Technical details |
| Bus bandwidth |
6.4 |
| Bus type units |
GT/s |
| Processor brand name |
Intel Xeon |
| Last change |
63903513 |
| Product family |
Intel Xeon Processor E7 Family |
| Launch date |
Q2’11 |
| Status |
Discontinued |
| Bus speed |
6.4 GT/s |
| Processor cache |
24576 KB |
| Supported memory types |
DDR3-SDRAM |
| Product type |
Processor |
| Packaging data |
| Package type |
Retail box |
| Weight & dimensions |
| Processor package size |
49.17mm x 56.47mm |
| Other features |
| Maximum internal memory |
2 TB |
