Datamax O’Neil M-4210 label printer Direct thermal 203 x 203 DPI 254 mm/sec Wired Ethernet LAN
- Direct thermal
- 203 x 203 DPI
- Maximum printing width: 10.8 cm Print speed: 254 mm/sec
- Built-in barcodes: 1D, 2D
- Connectivity technology: Wired
- USB port Ethernet LAN
- Display: LCD 128 x 64 pixels Backlight display
- 12.2 kg
M-Class™ Mark II printers offer great value for warehouse, healthcare, logistics and retail applications. They keep up with high-label-demand applications, boasting faster performance than many printers in their class. M-Class printers also feature a modular design and field-installable options to cut back on downtime and improve efficiency.
Rugged Construction
Features a durable precision die-cast aluminum frame and clear side window so you can easily monitor media supply levels.
User-Friendly LCD Graphics Display
Five-button, 128×64 LCD graphics backlit display is easy to read, enabling user-friendly label configuration setup.
5 Languages to Choose From
Multi-language menu available in English, Spanish, German, Italian and French.
Easy to Integrate
Features widely used DPL and supports PL-Z and PL-I printer-language emulations for easy integration into your existing applications.
Easy to Maintain
Modular design makes maintenance and part replacement easy. IntelliSEAQ™ printhead includes proactive diagnostic tools for easy access to printhead performance and history.
Easy to Upgrade
Field installable options such as cutters, peel & present sensors, and thermal transfer capabilities can be added easily to upgrade a base printer.
Available With RFID
Supports UHF and HF RFID configurations for current or future requirements, protecting your printer investment.
| Printing | |
|---|---|
| Maximum printing width | 10.8 cm |
| Print speed | 254 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Colour | No |
| Print technology | Direct thermal |
| Paper handling | |
|---|---|
| Media thickness | 0.0635 – 0.254 mm |
| Supported paper width | 19 – 118.1 mm |
| Maximum roll diameter | 20.3 cm |
| Core diameter | 7.62 cm |
| Ribbon length | 450 m |
| Ribbon width | 11.4 cm |
| Ports & interfaces | |
|---|---|
| Optional connectivity | Wireless LAN |
| RS-232 ports | 1 |
| Parallel ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB port | Yes |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Connectivity technology | Wired |
| Performance | |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, EAP-FAST, EAP-PEAP, EAP-TTLS, WEP, WPA-TKIP, WPA2, WPA2-AES, WPA2-CCMP |
| Image formats supported | BMP, IMG, PCX |
| Built-in barcodes | 1D, 2D |
| Flash memory | 8 MB |
| Internal memory | 16 MB |
| Page description languages | BPL, IPL, ZPL |
| Design | |
|---|---|
| Backlight display | Yes |
| Display resolution | 128 x 64 pixels |
| Display | LCD |
| Built-in display | Yes |
| Product colour | Black |
| Power | |
|---|---|
| AC input frequency | 47 – 63 Hz |
| AC input voltage | 90 – 264 V |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 4 – 35 °C |
| Weight & dimensions | |
|---|---|
| Weight | 12.2 kg |
| Height | 259 mm |
| Depth | 462 mm |
| Width | 257 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Other features | |
|---|---|
| Clock function | Yes |
| Navigation key | Yes |
| Languages support | Multi |
