Axis 02403-003 network video recorder Black
- AXIS Camera Station licenses included; All-in-one solution with integrated PoE switch; Ease of installation; Ideal for basic surveillance needs; Validated with extensive support
This affordable, all-in-one appliance includes a VMS client/server, storage, and an integrated PoE switch—all validated to meet the demands for reliable, basic surveillance up to 1080p. Designed to fit almost everywhere, AXIS S2108 is one of the most compact recorders on the market. It comes preloaded with AXIS Camera Station and preconfigured software licenses, so out-of-the-box you get seamless and reliable integration to all your Axis network cameras. Extensively tested with a wide range of Axis products, this smart appliance is easy to install, use, and maintain. Furthermore, it includes an advanced replacement service and a 5-year hardware warranty.
| Performance | |
|---|---|
| Operating system installed | Windows 10 IoT Enterprise |
| Internal memory | 8192 MB |
| Maximum resolution | 1920 x 1080 pixels |
| Video recording modes | 720p, 1080p |
| Number of simultaneously playbacked channels | 9 channels |
| Video input channels | 8 channels |
| Wireless LAN features | |
|---|---|
| Wi-Fi | No |
| Hard drive | |
|---|---|
| RAID support | No |
| Total installed storage capacity | 2 TB |
| Number of HDDs supported | 1 |
| HDD capacity | 2 TB |
| Number of HDDs installed | 1 |
| Ports & interfaces | |
|---|---|
| Networking standards | IEEE 802.3at |
| Line-in | Yes |
| Audio output | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 8 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN (RJ-45) ports | 10 |
| Features | |
|---|---|
| LED indicators | HDD, PoE |
| Product colour | Black |
| Brand compatibility | Axis |
| Processor | |
|---|---|
| Built-in processor | Yes |
| Power | |
|---|---|
| Output current | 2.3 A |
| Power | 180 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 – 240 V |
| Power consumption (typical) | 27 W |
| Power consumption (max) | 30 W |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 10 – 90% |
| Operating relative humidity (H-H) | 10 – 90% |
| Operating temperature (T-T) | 0 – 40 °C |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Weight & dimensions | |
|---|---|
| Weight | 3.5 kg |
| Height | 44 mm |
| Depth | 230 mm |
| Width | 310 mm |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Cables included | AC |
| Quick installation guide | Yes |
