Axis 02370-001 bridge/repeater Network bridge Black
- Based on open standards; Combines analog and network audio; Easy integration with other systems; I/Os for buttons and relays; PoE for easy installation
AXIS C8110 Network Audio Bridge is a smart solution based on open standards for connecting and combining analog and digital audio systems. Thanks to the built-in AXIS Audio Manager Edge application you can get functionalities like zone management and content scheduling in existing analog systems. With SIP support it is possible to connect an IP telephony system for callouts in analog speakers. With analog audio input you can easily integrate your intercom system or music streaming box with network speakers from Axis.
| Wireless LAN features |
| Wi-Fi |
No |
| Network |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.1x, IEEE 802.3at |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| DC-in jack |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Features |
| LED indicators |
Yes |
| Product colour |
Black |
| Mounting type |
Shelf/wall-mounted |
| Product type |
Network bridge |
| Power |
| Power consumption (typical) |
1.85 W |
| Power consumption (max) |
4 W |
| DC input voltage |
8 – 28 V |
| Power source type |
DC, PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-40 – 65 °C |
| Operating relative humidity (H-H) |
10 – 85% |
| Operating temperature (T-T) |
-20 – 50 °C |
| Certificates |
| Certification |
CISPR 35, CISPR 32 Class B, EAC, EN 55035,EN 55032 Class B, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), KC KN35, KN32 Class B, RCM AS/NZS CISPR 32 Class B, VCCI Class B |
| Weight & dimensions |
| Weight |
107 g |
| Height |
24 mm |
| Depth |
56 mm |
| Width |
128 mm |
| Other features |
| Warranty period |
5 year(s) |
| Packaging content |
| Quick installation guide |
Yes |
| Packaging data |
| Quantity per pack |
1 pc(s) |
